Kitchen Worktop Lift Granberg Baselift 6300 / 6310
BASELIFT 6300 / 6310 is a straight, motorised worktop lift.
Choose between wall-mounted or floor-mounted motors.
The lift can be used separately or together with Granberg's wall cabinet lift to totally adapt the kitchen. Space is left open below the work surface for knees and legs. Installations below the work surface, (motors, water, drainage), can be concealed by telescopic cover plates that give the kitchen an attractive appearance.
The motors are continuously adjustable and move the work surface quickly and silently to the required height. The lift is equipped with a reliable safety system that guarantees safe operation with no risk of crushing.
The equipment in the work surface is selected according to the function desired. Sink unit, hob, drawers, chopping boards and other accessories can be integrated in the work surface.
BASELIFT 6300 / 6310 is a straight, motorised worktop lift.
Choose between wall-mounted or floor-mounted motors.
The lift can be used separately or together with Granberg's wall cabinet lift to totally adapt the kitchen. Space is left open below the work surface for knees and legs. Installations below the work surface, (motors, water, drainage), can be concealed by telescopic cover plates that give the kitchen an attractive appearance.
The motors are continuously adjustable and move the work surface quickly and silently to the required height. The lift is equipped with a reliable safety system that guarantees safe operation with no risk of crushing.
The equipment in the work surface is selected according to the function desired. Sink unit, hob, drawers, chopping boards and other accessories can be integrated in the work surface.
BASELIFT 6300 / 6310 is a straight, motorised worktop lift.
Choose between wall-mounted or floor-mounted motors.
The lift can be used separately or together with Granberg's wall cabinet lift to totally adapt the kitchen. Space is left open below the work surface for knees and legs. Installations below the work surface, (motors, water, drainage), can be concealed by telescopic cover plates that give the kitchen an attractive appearance.
The motors are continuously adjustable and move the work surface quickly and silently to the required height. The lift is equipped with a reliable safety system that guarantees safe operation with no risk of crushing.
The equipment in the work surface is selected according to the function desired. Sink unit, hob, drawers, chopping boards and other accessories can be integrated in the work surface.
ADDITIONAL INFORMATION
-
Straight, motorised worktop lift
Height-adjustable 70-100 cm above floor (excl. countertop)
The frame depth is adjustable 56-59 cm to fit adjoining cabinet
The upper part of the lifting system is delivered ready-mounted. The sides are pre-assembled and adjustable sideways to suit the sink, hob and drawers
The lifting system is adjustable at an angle to compensate for an inclined wall
Integrated safety switch
10 cm free space under motors for electrical installation and piping. (Applies to wall-mounted model)
Choose floor-mounted model if there is no stable wall
-
Installation Wall-mounted
Front height 4.06" (103 mm
Height adjustment Motorized, steplessly adjustable 11.8" (300 mm), 27.6"-39.4" (700-1000 mm) excl. top board
Speed level 1.2" (30 mm) / sec.
Operation Recessed mounted button
Safety The safety strip is placed under the front edge of the worktop. If anything touches the safety strip, the lifting unit stops
Electrical connection Plug for 110 V, max 10A
Plumbing connections Connection is made with flexible hoses
Lifting force 220 lb (100 kg)
IP-class IP 20
Frame depth 22.0"- 23.2" (560-590 mm)
Dimensions cover plates 2 pcs, width = width of the lift -0.394" (-10 mm), height 17.24" (438 mm), thickness 0.472"-0.787" (12-20 mm)
Width worktop Width = width of the lift
Depth worktop 0.59" (15 mm) shallower than worktops on fixed cabinets
Space to wall / adjoining cabinet 0.197" (5 mm)
Space to wall (for tiles) 0.59" (15 mm)
Tiling From 27.56" (700 mm) above floor (alternatively all the way down to the floor)
Delivery modules Ready-mounted worktop incl. safety switch, motors
Fittings supplied Bracket for fronts
Material Aluminium frame
Warranty 3 years warranty Granberg makes a commitment to remedy material and manufacturing defects for a period of three years from the invoicing dat
-
The top board’s depth must be 0.6" (15 mm) shallower than adjoining top boards (to provide a gap for tiles and movement)
Width of the top board = width of the lift
Sink bowls with a maximum height of 4.7" (120 mm) can be integrated (not 6300L/6310L)
Electronics and motor system "Plug and Play"
Width of front = width of lift -0.2" (-4 mm)
Height of front:6300H/6310H = 4.1" (103 mm), 6300L/6310L = 1.6" (40 mm). Fittings enclosed
Cover panels can hide installations under the worktop 2 pcs width = width of lift -0.4" (-10 mm), height 17.2" (438 mm), thickness 0.5"-0.8" (12-20 mm).
